Name: Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-Freezing 0.5%FS Stability
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK80MA
Price: 21.00 USD
Availability: InStock

Rumah > Produk > Compact Pressure Sensor >

Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-Freezing 0.5%FS Stability

oem pressure sensor

precision pressure sensor

Compact Pressure Sensor Anti freezing

Tempat asal:

HEFEI, CINA

Nama merek:

WNK

Sertifikasi:

CE, SGS, ISO9001

Nomor model:

WNK80MA

Hubungi kami

Permintaan Penawaran

Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-Freezing 0.5%FS Stability

Product Details

Tekanan masukan:

0-1.6MPa

Stabilitas:

+/-0,5%FS, +/-1,0% FS (untuk opsi)

Elemen sensor:

Sensor Kapasitif Keramik

Tingkat Perlindungan:

IP67, IP65

jenis:

pengukur, absolut

Input tegangan:

5VDC, 12VDC, 24VDC, 9-30V dtk

Suhu Kerja:

-20C - 70C

Menyoroti:

oem pressure sensor

precision pressure sensor

Compact Pressure Sensor Anti freezing

Payment & Shipping Terms

Kuantitas min Order

5 potong

Harga

negotiable

Kemasan rincian

Pengepakan Layak Laut atau Pengepakan Layak Udara

Waktu pengiriman

7-10 hari kerja

Syarat-syarat pembayaran

T/T, Western Union, MoneyGram

Menyediakan kemampuan

5000 buah per bulan

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

Dapatkan Harga Terbaik

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

Dapatkan Harga Terbaik

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

Dapatkan Harga Terbaik

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

Dapatkan Harga Terbaik

Hubungi kami

Hubungi Sekarang

Product Description

Water Pump Compact Pressure Sensor 0.5-4.5V Output Anti-freezing 0.5%FS Stability

Description

WNK80MA is a series of high performance compact pressure Transmitter, by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 100 times of the range, completely solved poor overload in small range of other sensors. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement.

Technical Data

Applicable media	Liquid, Gas
Pressure range	0-1.6Mpa , 0-20Mpa, Customized
Pressure measurment	Gauge Pressure
Output	0.5-4.5V/4-20mA
Accuracy(linearity,Hysteresis and Repeatability)	0.5%F.S.(Typical), 1.0%FS ( for option)
Power supply	24VDC/12VDC/5VDC
Compensation temperature	-20~70ºC
Ambient temperature	-40~125ºC
Working temperature	-40~125ºC
Temperature drift(zero)	±0.15% F.S. (-20~85ºC)
Temperature drift(full range)	±0.15% F.S. (-20~85ºC)
power(electrical) connect	Parkard, M12, DIN43650, Cable outlet, Other
Mechanical connection	G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
Housing material	304 stainless steel

Application:

For oil,fuel,diesel,gas,water or air pressure.Can be used in oil tank,gas tank,diesel tank etc.
