Name: Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK80MA
Price: 21.00 USD
Availability: InStock

Rumah > Produk > Compact Pressure Sensor >

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input

electronic pressure sensor

precision pressure sensor

Compact Pressure Transmitter 100Kpa

Tempat asal:

HEFEI, CINA

Nama merek:

WNK

Sertifikasi:

CE, SGS, ISO9001

Nomor model:

WNK80MA

Hubungi kami

Permintaan Penawaran

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input

Product Details

Masukan:

-100Kpa - 70Mpa

Keluaran Digital:

I2C, SPI

Output analog:

4-20mA, 0,5-4,5VDC

Konektor Tekanan:

NPT1/8 G1/4 Disesuaikan

Akurasi linier:

0,5%FS, 1,0%FS

Overload Tekanan:

2-3 Kali

Bukti:

IP67

Menyoroti:

electronic pressure sensor

precision pressure sensor

Compact Pressure Transmitter 100Kpa

Payment & Shipping Terms

Kuantitas min Order

5 potong

Harga

negotiable

Kemasan rincian

Pengepakan Layak Laut atau Pengepakan Layak Udara

Waktu pengiriman

7-10 hari kerja

Syarat-syarat pembayaran

T/T, Western Union, MoneyGram

Menyediakan kemampuan

5000 buah per bulan

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

Dapatkan Harga Terbaik

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

Dapatkan Harga Terbaik

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

Dapatkan Harga Terbaik

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

Dapatkan Harga Terbaik

Hubungi kami

Hubungi Sekarang

Product Description

Digital Hydraulic Water Treatment Compact Pressure Sensor Pressure Transmitter

Description

WNK80MA is a series of high performance compact pressure Transmitter, by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 100 times of the range, completely solved poor overload in small range of other sensors. In addtion to general ranges of normal sensors, its most outstanding characteristic is the positive and negative gauge pressure function. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement

Specifications

Applicable media	Liquid, Gas
Pressure range	0-7kPa~350bar
Pressure measurment	Gauge Pressure, Absolute pressure, Sealing pressure
Output	4-20mA/0.5-4.5V/1 -5V/0-10V/I2C
Accuracy(linearity,Hysteresis and Repeatability)	0.5%F.S.(Typical)
Power supply	24VDC/12VDC/5VDC/3.3V
Compensation temperature	-20~85ºC
Ambient temperature	-40~125ºC
Working temperature	-40~125ºC
Temperature drift(zero)	±0.15% F.S. (-20~85ºC)
Temperature drift(full range)	±0.15% F.S. (-20~85ºC)
power(electrical) connect	Parkard, M12, DIN43650, Cable outlet
Mechanical connection	G1/4, 1/4NPT, 1/8NPT, M12*1.5, customize
Housing material	304 stainless steel(inner core is 316 stainless steel)
Protection	IP65

Application:

For oil,fuel,diesel,gas,water or air pressure.Can be used in oil tank,gas tank,diesel tank etc.

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input 0

Digital Hydraulic Water Compact Pressure Transmitter -100Kpa - 70Mpa Input 1
