100psi / 150psi / 200psi Compact Pressure Sensor For Air Compressor / Pump

oem pressure sensor

precision pressure sensor

Compact Pressure Sensor IP68

Tempat asal:

HEFEI, CINA

Nama merek:

WNK

Sertifikasi:

CE, SGS, ISO9001

Nomor model:

WNK80MA

Hubungi kami

Permintaan Penawaran

100psi / 150psi / 200psi Compact Pressure Sensor For Air Compressor / Pump

Product Details

Kapasitas:

-100Kpa - 600mbar

Masukan Daya:

5VDC

Ketepatan:

+/-0,5%, 1,0%FS

Waktu Respons:

<=2,0 mdtk

Suhu Kerja:

-40C~70C

Keluaran:

0.5V-4.5V

Perlindungan Masuknya:

IP68

Menyoroti:

oem pressure sensor

precision pressure sensor

Compact Pressure Sensor IP68

Payment & Shipping Terms

Kuantitas min Order

5 potong

Harga

negotiable

Kemasan rincian

Pengepakan Layak Laut atau Pengepakan Layak Udara

Waktu pengiriman

7-10 hari kerja

Syarat-syarat pembayaran

T/T, Western Union, MoneyGram

Menyediakan kemampuan

5000 buah per bulan

Explosion Proof Compact Pressure Sensor With 4~20mA And High Accuracy 0.2%FS

Dapatkan Harga Terbaik

Ceramic Capacitive 15MPa IP65 I2C Water Pressure Sensor

Dapatkan Harga Terbaik

WNK 0.5-4.5V 4 - 20ma Pressure Transmitter 150Psi IP65

Dapatkan Harga Terbaik

WNK 0.5-4.5V 4-20ma Smart Absolute Gauge Pressure Sensor For Water Air Oil

Dapatkan Harga Terbaik

Hubungi kami

Hubungi Sekarang

Product Description

100psi 150psi 200psi Compact Pressure Sensor Transducer For Air Compressor, Pump

Name: 100psi / 150psi / 200psi Compact Pressure Sensor For Air Compressor / Pump
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK80MA
Price: 21.00 USD
Availability: InStock

Description

1. Suitable for all kinds of hydraulic, pneumatic pressure measurement

2.Suitable for civil use product batch

3.Static accuracy: plus or minus 0.5% or 1.0% FS

4.Pressure range can be customized according to customer requirements

5.Wide range of temperature compensation

6.Medium for non-corrosive gas, water, oil, etc

Features:

Easy removal, carbon steel connection more firmly.

Stainless steel is durable, sealed waterproof line, imported chips.

Wiring: red +, black -, yellow output

Specification:

Working Voltage: 5.0 VDC, or other 9-30VDC

Output Voltage: 0.5-4.5 VDC, 4-20ma, and other

Working Current: <=10 mA

The Biggest Pressure: 3-5 times

Working Temperature Range:-40-70 Celsius Degree

Storage Temperature Range: 0-100 Celsius Degree

Measuring Error: +_ 1.5 %FSO

Response Time: <=2.0 ms

Cycle Life: 500,000 pcs
