Name: 4-20mA Diffused Silicon IOT Water Pressure Sensor G1/4 For Air Gas
Brand: Hefei WNK Smart Technology Co.,Ltd
SKU: WNK811ma
Price: 25.00 USD
Availability: InStock

Rumah > Produk > Water Pressure Sensor >

4-20mA Diffused Silicon IOT Water Pressure Sensor G1/4 For Air Gas

Diffused Silicon IOT water pressure sensor

G1/4 IOT water pressure sensor

G1/4 iot proximity sensor

Tempat asal:

Cina

Nama merek:

WNK

Sertifikasi:

CE/ROHS

Nomor model:

WNK811ma

Hubungi kami

Permintaan Penawaran

4-20mA Diffused Silicon IOT Water Pressure Sensor G1/4 For Air Gas

Product Details

Kisaran tekanan:

-1~600Bar

Keluaran:

I2C, 0,5-4.5V, 4-20mA Dan Kustomisasi

Jenis Sensor:

Sensor Tekanan IOT

Ketepatan:

Ketepatan

Suhu kompensasi:

-20 -70°C

Bahan perumahan:

baja tahan karat 304

Port tekanan:

G1/4, G1/2 ,1/8NPT, 1/4NPT, lainnya

Menyoroti:

Diffused Silicon IOT water pressure sensor

G1/4 IOT water pressure sensor

G1/4 iot proximity sensor

Payment & Shipping Terms

Kuantitas min Order

1 harga

Harga

negotiable

Waktu pengiriman

5-8 Hari Kerja

Syarat-syarat pembayaran

T/T, Western Union

Menyediakan kemampuan

5000 Potongan/potongan per Bulan Pemancar Tekanan

Transmitter tekanan industri dengan catu daya 5VDC dan bahan rumah tahan korosi SS304

Dapatkan Harga Terbaik

Diffused Silicon Pressure Sensor 4-20ma 5V 24V Robust Transmitter yang dirancang untuk kinerja pemantauan tekanan jangka panjang

Dapatkan Harga Terbaik

100 Psi WNK Vacuum Pressure Transmitter 4 - 20ma 0 - 10V

Dapatkan Harga Terbaik

I2C 4-20MA 0.5-4.5V Diffused Silicon Cpmpact Pressure Sensor For Corrosive Media

Dapatkan Harga Terbaik

Hubungi kami

Hubungi Sekarang

Product Description

Low Cost 4-20mA Diffused Silicon Pressure Sensors

Pressure Type	Gauge Pressure , Absolute Pressure, Sealing Pressure
Pressure Range	-1 - 60Mpa
Accuracy	0.5%FS
Power Supply	5VDC, 12-32VDC
Measuring Media	Gas, Steam, Liquid, Oil
Output
Analog	4-20mA, 0.5-4.5V, Other
Digital	I2C,
Operation Condition and Temperature
Compensation Temperature	-40...75℃
Medium Temperature	-45 ... 85℃
Storage Temperature	-45 ... 85℃
Material and Protection
Ingress Protection	IP65, IP67
Housing Material	304SS, 316L

Applications

- Automobile, Compressor and Refrigeration Industry

- Engineering machinery

- Pressure control and monitor

- Water treatment system

- Hydraulic and Pneumatics

- HAVC and BAS Control

- Pump, fitness equipment, household appliances

- Factory Automation

- Fluid Control and Instrumentation Systems

WNK811 is a series of high performance compact pressure transducer, by using ASIC signal conditioning chip and dry ceramic capacitive pressure sensor. It has features of anti-corrosion, anti-wear, shock resistance and vibration resistance. Its anti-overload capacity is up to 10 times of the range, completely solved poor overload in small range of other sensors. In addtion to general ranges of normal sensors, its most outstanding characteristic is the positive and negative gauge pressure function. With high output and wide range, WNK80MA is especially suitable for manufacturing of high-performance industrial control pressure transmitter and harsh environment pressure measurement.

Electrical Connections

4-20mA Diffused Silicon IOT Water Pressure Sensor G1/4 For Air Gas 0

Pressure Port

4-20mA Diffused Silicon IOT Water Pressure Sensor G1/4 For Air Gas 1

Product Show

4-20mA Diffused Silicon IOT Water Pressure Sensor G1/4 For Air Gas 2

Hot Product

4-20mA Diffused Silicon IOT Water Pressure Sensor G1/4 For Air Gas 8

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
